I will model wood and timber house framing structure in sketchup 3d
Hi, I'm Fernando, specialized in 3D modeling for architecture
Sobre este Serviço
Thank you for considering my service.
I will model your house structure using wood framing system, providing an initial structural volumetric concept for the project. This model can support design, planning, quantity takeoffs, and can also be used for rendering or animation purposes.
I will model everything following industry standards, as well as the plans, details, and specifications you provide.
Please note: this 3D file is not for construction and must be reviewed by a structural engineer if used for that purpose.
The 3D model includes:
- Studs
- Columns
- Post
- Header/Lintel
- Ceiling joist
- Beams
- Floor system
- Truss or Rafter roof
- OSB/Plywood, insulation, cladding and any sheet board material modeling (extra)
- Doors and windows modeling (extra)
All components are properly organized and grouped in layers, making it easy for you to view and edit them in SketchUp.
Feel free to ask any questions. I'll be glad to help you!
Modeling of foundation, steelwork, reinforcement, connectors, concrete/masonry walls, electrical and plumbing are not included.
Escala de Projeto:
House
Especialidade de material:
Madeira
•
Outros
Preferência de estilo de entrega
Informe o freelancer sobre suas preferências ou preocupações em relação ao uso de ferramentas de IA na conclusão e/ou entrega de seu pedido.
Perguntas frequentes
Do you do structural calculations?
Within the scope of my services, I do not offer structural calculations
Do you also provide structural drawings?
No, this is not included in my services at the moment.
