I will design a custom mechanical keyboard pcb and schematics

Algumas informações são exibidas no idioma inglês.
4,9
4,9

Sri Lanka

Eu falo Inglês

619 pedidos finalizados

Bringing your ideas to life with reliable engineering solutions!

I'm an enthusiast in electronics who process 12+ years of experience in Electronic circuit designing and PCB designing. My main focuses are IoT, Power Electronics, Industrial Automation, and Audio Ele...

Nível 1

Atendeu a determinados critérios de desempenho e demonstra forte potencial no marketplace.

O que as pessoas adoram neste freelancer

Sobre este Serviço

I have 8 years of experience in designing PCB for Digital electronics and I will design your Custom Mechanical Keyboard PCB according to professional design guidelines.


Features for all packages


  • Standard MX, Low profile or custom keys
  • Hot Swap sockets
  • QMK compatible schematics
  • Atmega32U4, STM32 or any QMK supported MCU
  • USB complaint circuits with all protection features.
  • Any type of USB connector including Type C


Capabilities (Additional fees might apply)


  • Highly customized non standard matrices and layouts
  • RGB under key glow and backlit
  • Num Pads, 60% - 65%, TKL, Full sized or split keyboards
  • Onboard USB hubs for Num Pads and Split keyboards
  • Non Standard key types
  • Wireless connectivity
  • OLED screens, Encoders and other extra peripherals.
  • Integrated Battery support and USB Type C PD
  • Custom QMK firmware with VIA/VIAL


You will receive


  • KiCAD Project files
  • All fab files including Gerber and PnP files
  • Schematics
  • Bill of Materials
  • Standard 3D renderings


Please contact me with your keyboard layout or details before placing the order.


A photo of the keyboard or layout created at http://www.keyboard-layout-editor.com/ will be ideal.


Thank you!
