Hello, I'm Chad, an Electronics and PCB Design Engineer specializing in PCB layout, schematic design, circuit development, and manufacturing-ready PCB solutions. I work with Altium Designer, KiCad, EasyEDA, and Eagle CAD to deliver high-quality single-layer, multi-layer, and high-speed PCB designs. My services include schematic capture, PCB routing, Gerber files, BOM creation, DFM checks, and PCB redesign. I focus on accuracy, fast delivery, clear communication, and reliable results for every project. Contact me before placing your order and Let's build your next PCB together... Saiba mais

Habilidades

c
chad_harry
Chad
offline •
Tempo médio de resposta: 1 hora

Conheça meus serviços

Circuito Impresso (PCB)
I will design schematic pcb circuit in kicad, altium, easyeda and optimize pcb layout
Circuito Impresso (PCB)
I will do electronics engineering circuit design, pcb electrical engineering, robotics

Experiência profissional

Engineerforce

Smart IoT Monitoring System [KiCad PCB Design]

Engineerforce

Aug 2025 - Oct 20252 mos

Designed a 2-layer PCB in KiCad for an IoT-based monitoring system utilizing an ESP32 microcontroller, environmental sensors, voltage regulation circuits, and communication interfaces. Created complete schematics, performed component selection, optimized PCB layout, and routed signal and power traces while maintaining EMI and manufacturing considerations. Generated Gerber files, BOM, and pick-and-place files for production. Conducted design rule checks (DRC) and verified manufacturability to ensure reliable performance and cost-effective fabrication. The project improved system integration, reduced wiring complexity, and provided a compact, production-ready hardware solution.
